The SN® Mini connector is the shortest connector in the SN family and offers users the most space-efficient solution for applications demanding optimized BTW (Behind The Wall) space-saving. In combination with SN Mini connectors, as much as 14.1mm can be saved compared with standard adapters and connectors, making it the ideal solution for opto-electronic applications requiring circuit boards or other vital components to share the same space as fiber optic connectivity.
- Use only with SN Mini Adapters
- Latch locking mechanism
- Accepts 2 x 900 μm buffered fibers
- Extra small for space-limited installations
Parameters | Single-mode | Multimode | |||
UPC | APC | MM | |||
SM Premium Low Loss | SM Premium | SM Premium Low Loss | SM Premium | Premium | |
Typical Insertion Loss (dB)* | 0.05 | 0.08 | 0.07 | 0.12 | 0.05 |
Max Insertion Loss (dB)* | 0.15 | 0.20 | 0.15 | 0.25 | 0.15 |
Typical Return Loss (dB) | ≥55 | ≥65 | ≥25 | ||
Operating Temperature (°C) | -40 to +75 | ||||
Durability | <0.2dB typical change, 500 mating’s | ||||
Ferrule Ø | 125μm | 127μm |
* Per random mating testing IEC 61753-1
- Coherent Optic Systems
- WDM systems
- Optoelectronic devices
- MUX/DEMUX Applications
- Automated Robotic Switches
- Ultra-short cassettes and modules
![SN-Mini-Application SN-Mini-Application](https://www.senko.com/wp-content/uploads/2021/08/SN-Mini-Application-300x188.png)
![logo-rosh](https://www.senko.com/wp-content/uploads/2021/09/logo-rosh-120x120.png)
![Reach logo](https://www.senko.com/wp-content/uploads/2021/09/Reach-Website-120x120.jpg)
![IEC logo](https://www.senko.com/wp-content/uploads/2021/09/IEC-Website-120x99.jpg)
![TIA logo](https://www.senko.com/wp-content/uploads/2021/09/TIA-Website-120x84.jpg)
![GR-326-Website](https://www.senko.com/wp-content/uploads/2021/09/GR-326-Website-120x112.jpg)
The SN Connector can be used in temperatures as low as -40°C and up to 75°C.
The SN Junior connector utilizes a latch. press the latch and it will release the connector from the adapter.
It will use 2 individual buffered fibers. Up to 900µm diameter.
The SN Junior will fit anything but a Compact or Mini series adapter.
