SENKO’s LC EZ-FLIP® is the easiest to use and quickest polarity reversing Duplex Uniboot connector available. Reduced profile latch mechanism and push-pull tab option for high density Data Center and Telco central office applications.
- Stackable for high density Data Center
- Polarity Reversal without twisting fiber
- Push-Pull tab option
- Preassembled version for ease of termination
- Visual indicator for polarity reversal
- Uniboot aids in cable management
| Parameters | Single-mode | Multimode |
| UPC | MM | |
| Standard | ||
| Typical Insertion Loss (dB) | 0.12 | 0.15 |
| Max Insertion Loss (dB) | 0.30 | 0.30 |
| Typical Return Loss (dB) | ≥55 | ≥25 |
| Operating Temperature (°C) | – 40 to +75 | |
| Durability | <0.2dB typical change, 500 matings | |
| Ferrule Ø | 125.5μm | 127μm |
Data Center
Wireless
FTTH
Telecommunications
The LC EZ-Flip connector can be used in temperatures as low as -40°C and up to 75°C.
The length is 47mm with 2&3mm boots.
Yes, they are available in 34, 51 and 67mm lengths.
